S-Plastic Thermocomp 2F005 is a fluoropolymer compound based on ETFE containing Glass Fiber.

Product Categories
SAMTION INTERNATIONAL LIMITED
Contact Now

S-Plastic Thermocomp 2F005 is a fluoropolymer compound based on ETFE containing Glass Fiber.

  • 1
  • 2
  • 3

Brand Name : S-Plastic Thermocomp

Model Number : 2F005

Certification : Datasheet，MSDS，ROHS，SGS，REACH，FDA，EU，UL，COC/COA ,please contact us

Place of Origin : ——

MOQ : 100KG

Price : *USD

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : To be negotiated

Delivery Time : To be negotiated

Packaging Details : 25KG/bag

Melt Volume Rate, MVR at 260°C/2.16 kg : ？？？

UL Recognized, 94HB Flame Class Rating (3) : ？？？

Contact Now

S-Plastics Thermocomp 2F005 resin is a fluoropolymer compound based on ETFE containing Glass Fiber.

​Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 5 mm/min 61 MPa ASTM D 638
Tensile Stress, brk, Type I, 5 mm/min 59 MPa ASTM D 638
Tensile Strain, yld, Type I, 5 mm/min 7 % ASTM D 638
Tensile Strain, brk, Type I, 5 mm/min 8.1 % ASTM D 638
Tensile Modulus, 50 mm/min 6190 MPa ASTM D 638
Flexural Modulus, 1.3 mm/min, 50 mm span 5480 MPa ASTM D 790
Tensile Stress, yield, 5 mm/min 61 MPa ISO 527
Tensile Stress, break, 5 mm/min 60 MPa ISO 527
Tensile Strain, yield, 5 mm/min 6.6 % ISO 527
Tensile Strain, break, 5 mm/min 7 % ISO 527
Tensile Modulus, 1 mm/min 5670 MPa ISO 527
Flexural Stress 87 MPa ISO 178
Flexural Modulus, 2 mm/min 5200 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, unnotched, 23°C 1600 J/m ASTM D 4812
Izod Impact, notched, 23°C 529 J/m ASTM D 256
Multiaxial Impact 10 J ISO 6603
Instrumented Impact Total Energy, 23°C 21 J ASTM D 3763
Izod Impact, unnotched 80*10*4 +23°C 90 kJ/m² ISO 180/1U
Izod Impact, notched 80*10*4 +23°C 44 kJ/m² ISO 180/1A
THERMAL Value Unit Standard
HDT, 0.45 MPa, 3.2 mm, unannealed 248 °C ASTM D 648
HDT, 1.82 MPa, 3.2mm, unannealed 190 °C ASTM D 648
CTE, -30°C to 30°C, flow 6.4E-05 1/°C ASTM D 696
CTE, -30°C to 30°C, xflow 6.1E-05 1/°C ASTM D 696
HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm 232 °C ISO 75/Bf
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 132 °C ISO 75/Af
PHYSICAL Value Unit Standard
Specific Gravity 1.87 - ASTM D 792
Density 1.87 g/cm³ ASTM D 792
Moisture Absorption, 50% RH, 24 hrs 0.01 % ASTM D 570
Mold Shrinkage, flow, 24 hrs (5) 1 - 3 % ASTM D 955
Mold Shrinkage, xflow, 24 hrs (5) 2 - 4 % ASTM D 955
Moisture Absorption (23°C / 50% RH) 0.02 % ISO 62
Source GMD, last updated:2010/08/10

Processing

THESE PROPERTY VALUES ARE NOT INTENDED FOR SPECIFICATION PURPOSES.
PLEASE CHECK WITH YOUR (LOCAL SALES OFFICE) FOR AVAILABILITY IN YOUR REGION
(1) Typical values only. Variations within normal tolerances are possible for various colors. All values are measured after at least 48 hours
storage at 23°C/50% relative humidity. All properties, except the melt volume and melt flow rates, are measured on injection molded
samples. All samples tested under ISO test standards are prepared according to ISO 294.
(2) Only typical data for selection purposes. Not to be used for part or tool design.
(3) This rating is not intended to reflect hazards presented by this or any other material under actual fire conditions.
(4) Internal measurements according to UL standards.
(5) Measurements made from laboratory test coupon. Actual shrinkage may vary outside of range due to differences in processing
conditions, equipment, part geometry and tool design. It is recommended that mold shrinkage studies be performed with surrogate or
legacy tooling prior to cutting tools for new molded article.
